4.5Ah LiFePO4 Emergency Lighting Battery
Replacement Emergency Lighting Batteries
Application
Emergency Lighting Battery
Emergency Lighting Battery
Height (mm)
23
23
Length (mm)
228
228
Width (mm)
22
22
Product Description
These 4.5Ah Lithium Iron Phosphate (LiFePO4) batteries are compliant with EN 62133-2. Their higher energy density compared with equivalent NiMH batteries allows more energy to be stored within the same physical space, providing a compact and efficient battery solution.
When operated within the specified temperature range, the batteries are designed to provide a four-year service life in accordance with the requirements of EN 60598-2-22.
End caps are supplied with all battery sticks and these should be securely fastened to the gear tray or luminaire body with screws.
Key Features
- Four-year service life
- Complies with EN 60598-2-22
Available Specification
Application | Emergency Lighting Battery |
Battery Type | 4.5Ah LiFeP04 |
Height (mm) | 23 |
Length (mm) | 228 |
Max Temp (°C) | 0 to +25°C for 12 months or 0 to +35°C for 6 months at a relative humidity <60%. |
Weight (kg) | 0.138 |
Width (mm) | 22 |
Files
Technical Datasheet |
